Home Assistant: motion sensor coupled with a switch

How you can control a light with motion sensor but only if did not controlled your light in a different way

Marco Mornati's photo
Marco Mornati
ยทJan 2, 2023ยท

5 min read

Did you already move your harms to your motion sensor to power on your external light, for example when you are on your deck having dinner? It happened all the time to me and it is really frustrating... so I created automation to stop it! ๐Ÿ˜Ž

What do you need?

  • A smart bulb (or equivalent to control a bulb)

  • A smart motion sensor

  • A input_boolean to check the way the light is powered on

Input Boolean

Nothing special here, you just need to put it within your input_boolean.yaml file or directly in the configuration.yaml, depending on how you are managing your HassIO configuration.
To simplify my global configuration, on my side I put this within the global configuration file: input_boolean: !include components/input_boolean.yaml

input_boolean: !include components/input_boolean.yaml

Which then allows you to put all your booleans configurations within the defined file.

A different way to include external files, which I'm using with automation, is to put a folder instead of a file and ask Home Assistant to merge everything to get the final configuration:automation: !include_dir_merge_list automations/

automation: !include_dir_merge_list automations/

This allows your automation folder to put 1 YAML per automation and so separate it to simplify the management.

Anyway, getting back to our boolean. What you have to put inside the external file is:

terrasse_salon_auto_on:
  name: Terrasse Salon Motion ON
  icon: mdi:lightbulb

This will create an input_boolean named terrasse_salon_auto_on we will use later in our automation.

The Automation

We have two different automation to control the power-on and the power-off.

- alias: Terrasse Salon ON
  id: terrasse_salon_on
  trigger:
    platform: state
    entity_id: binary_sensor.motion_salon_occupancy
    to: "on"
  condition:
    - condition: state
      entity_id: light.terrasse_salon
      state: "off"
    - condition: numeric_state
      entity_id: sensor.motion_salon_illuminance_lux
      below: 50
    - condition: state
      entity_id: input_boolean.terrasse_motion_sensor_enabled
      state: "on"
  action:
    - service: light.turn_on
      entity_id: light.terrasse_salon
    - service: input_boolean.turn_on
      entity_id: input_boolean.terrasse_salon_auto_on

- alias: Terrasse Salon OFF
  id: terrasse_salon_off
  trigger:
    platform: state
    entity_id: binary_sensor.motion_salon_occupancy
    to: "off"
    for:
      minutes: 2
  condition:
    - condition: state
      entity_id: light.terrasse_salon
      state: "on"
    - condition: or
      conditions:
        - condition: state
          entity_id: input_boolean.terrasse_salon_auto_on
          state: "on"
        - condition: state
          entity_id: input_boolean.ignore_light_manual_on
          state: "on"
  action:
    - service: light.turn_off
      entity_id: light.terrasse_salon
    - service: input_boolean.turn_off
      entity_id: input_boolean.terrasse_salon_auto_on

As usual, we will enter each part of the script to understand what it does.

The Trigger

We want to turn on and off the light bulb when motion is detected. So we will use a state trigger on this particular sensor.

trigger:
    platform: state
    entity_id: binary_sensor.motion_salon_occupancy
    to: "on"

When the occupancy sensor of the motion sensor is moving to on the script is triggered.

For the off part, we improve a little bit the trigger to prevent the light from flickering all the time if we are outside but not always moving or not always in front of the motion sensor.

trigger:
    platform: state
    entity_id: binary_sensor.motion_salon_occupancy
    to: "off"
    for:
      minutes: 2

The for minutes is doing the job: if the occupancy is off for at least 2 minutes, the action is triggered.

The Conditions

If there is motion, when do we want to power on the light? If it is dark and if, for sure, the light is off. So, this is mainly what we find:

condition:
    - condition: state
      entity_id: light.terrasse_salon
      state: "off"
    - condition: numeric_state
      entity_id: sensor.motion_salon_illuminance_lux
      below: 50
    - condition: state
      entity_id: input_boolean.terrasse_motion_sensor_enabled
      state: "on"
  • The state part is checking if the light is off

  • The numeric_state is validated by the illuminance value provided by the motion sensor. Which value to put here? Just made some tests. 0 should be a good value (no light at all) but I preferred to move a little bit up to have the power bulb powered on with low illuminance.

  • The last state is another input_boolean I added to be able to completely prevent light from being powered on. I'm using this during the night: if the night alarm is on, this means nobody will go outside, so I don't want to have the lights powered on by movements.

For the power-off action, there is something similar, but it is here we will use the added input boolean to do the magic.

  condition:
    - condition: state
      entity_id: light.terrasse_salon
      state: "on"
    - condition: or
      conditions:
        - condition: state
          entity_id: input_boolean.terrasse_salon_auto_on
          state: "on"
        - condition: state
          entity_id: input_boolean.ignore_light_manual_on
          state: "on"
  • The state of the light. It sure must be on

  • The state input_boolean we previously configured. We will power off the light bulb if it was automatically turned on (we will see in a while when this flag will be turned on). This means if we power on the light with the home assistant application or if a switch, the flag should be false and the light won't be turned off.

  • Here you will see a or condition with a second input_boolean.ignore_light_manual_on. I'm using it to disable the previous flag: If I want to turn off anyway the light, never mind how it was turned on.

The Action

If everything is validated the light should be turned on or off, depending on the automation we are considering, but not only: we will control the input_boolean at this level.

  action:
    - service: light.turn_on
      entity_id: light.terrasse_salon
    - service: input_boolean.turn_on
      entity_id: input_boolean.terrasse_salon_auto_on

You can see in the turn-on script, two services are fired: one for the light itself and the second one to move the boolean to true. This means if the light is turned on by the automation, the boolean contains the value to check this.
It is in my opinion the simple way to control this, but you can check in many other ways.

On the power-off part, it is exactly the opposite: we move the flag to false to get back to the initial state.

  action:
    - service: light.turn_off
      entity_id: light.terrasse_salon
    - service: input_boolean.turn_off
      entity_id: input_boolean.terrasse_salon_auto_on
